Description: 1. The L298N is a dual full-bridge driver IC specifically designed for controlling DC motors or stepper motor applications. It offers two independent channels for driving two motors. 2. Each channel of the L298N can provide a continuous current of up to 1.2A and a peak current of 1.6A, making it suitable for small to medium-sized DC motors. 3. This motor driver IC features four input control pins (IN1-IN4) that allow for half-bridge or full-bridge motor connection configurations, accommodating various motor setups. 4. The L298N has built-in overload protection, preventing the motor from receiving excessive current and damaging both the driver and the connected components. 5. It provides separate enable pins (EN1 & EN2) that enable or disable each motor channel independently for better control and precision in your projects. 6. The L298N motor driver IC comes with a diode protection circuit on the output to ensure proper current flow during regenerative braking, preventing damage
| Specification | Details |
|---|---|
| Manufacturer | STMicroelectronics |
| Package Type | DIP-38 (Dual In-Line Package) |
| Operating Voltage | 4.5V to 46V |
| Current Rating | up to 2A per channel |
| Input Logic Level | TTL CMOS |
| Supply Current | 1.5mA (typical) 10mA (max) |
| Thermal Resistance | 35°C/W |
| Operating Temperature | -40°C to 85°C |
| Pinout Configuration | H-Bridge Dual Full-Bridge Motor Driver |
| Functionality | Dual full-bridge motor driver with built-in thermal shutdown and overcurrent protection |
| Application | Robotics automotive industrial automation home appliances |
